Fujitsu Primergy RX2540 M4 Rack Server, 2x Gold 5122 3.60GHz, 4 Core, 32GB DDR4, 2x 450GB SSD (8x SFF), EP400i
Product information
Performance, scalability, reliability – this is what the Fujitsu Primergy RX2540 M4 rack server offers.
Are you looking for a reliable, secure, and powerful server? Are you future-oriented and value flexibility? Then the Primergy server family is exactly what you need. With powerful Intel Scalable processors and up to 3 TB of RAM, the Fujitsu RX2540 M4 server offers the ideal platform for server virtualization or consolidation, impressing with its outstanding performance, user-friendliness, and optimal scalability. The compact and ultra-dense 2U rack server is ideal for demanding and compute-intensive workloads, such as databases and big data analytics. In addition, Primergy servers are characterized not only by their energy efficiency, but also by their longevity.
Product Highlights:
- Powerful processor: expandable to up to two processors from the Intel XEON Scalable family (with up to 28 cores)
- RAM: 32 GB installed / expandable to up to 3072 GB DDR4 RAM (24 memory slots / 12 DIMMs per CPU, 6 channels with 2 slots per channel)
- A RAM upgrade can be configured directly online at serverando.de
- Expandable to up to 8x 2.5" SFF HDDs or SSDs (hot-plug)
- Fujitsu PRAID EP400i RAID controller installed (RoC LSI SAS3108 / 12 Gbit/s) PCIe 3.0 x8) for RAID levels 0, 1, 10, 5, 50, 6, 60
- Redundant, highly efficient power supplies
- Redundant hot-pluggable fans
- Rack-optimized & space-saving 2U chassis
Product details:
- Mainboard type: D3384
- Chipset: Intel C624
- Dimensions: Rack (W x D x H) 482.4 mm (front panel) / 445 mm (chassis) x 770 x 86.6 mm, 740 mm rack installation depth
- Interfaces: 5 x USB 3.0 (2 x front, 2 x rear, 1 x internal), 1 x VGA, 1 x serial RS-232-C optional (usable for iRMC or system or shared), 1 x dedicated management LAN port for iRMC S5 (RJ-45, 10/100/1000 Mbit/s)
- Supported operating systems and virtualization software according to the Fujitsu data sheet: Windows Server 2019 Datacenter, Windows Server 2019 Standard, Windows Server 2019 Essentials, Windows Server Datacenter version 1809, Windows Server Standard version 1809, Hyper-V Server 2016, Windows Server 2016 Datacenter, Windows Server 2016 Standard, Windows Server 2016 Essentials, Windows Storage Server 2016 Standard, Windows Server Datacenter version 1709, Hyper-V Server 2012 R2, Windows Server 2012 R2 Datacenter, Windows Server 2012 R2 Standard, Windows Server 2012 R2 Essentials, Windows Storage Server 2012 R2 Standard, VMware vSphere 6.7, VMware vSphere 6.5, VMware vSphere 6.0, SUSE Linux Enterprise Server 12, SUSE Linux Enterprise Server 11, Red Hat Enterprise Linux 8, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 6, Oracle Linux 7, Oracle Linux 6, Oracle VM 3, Univention Corporate Server 4
✓ Expand your IT landscape cleverly and cost-effectively with used hardware from the professional sector. Thoroughly tested, professionally refurbished, and of top quality. At the same time, you're making a valuable contribution to environmental protection: the more hardware is reused, the less new hardware needs to be produced. Achieve greater sustainability with "Green IT"!
| Manufacturer/Brand: | Fujitsu |
|---|---|
| Manufacturer no: | S26361-K1567-V408 |
| Weight: | 16.04 kg |
| CPU cores: | 4-Core |
| CPU frequency: | 3.6 GHz |
| Condition: | Used & refurbished |
| Depth: | 77,00 cm |
| Fans: | 6x Hot-Plug |
| Hard drives: | 2x Fujitsu HDD 450GB 12G SAS 15k |
| Height: | 2U |
| Memory (RAM): | 32GB |
| Model: | Primergy RX2540 M4 |
| Number of CPU: | 2 CPUs |
| Optical drive: | DVD-RW |
| PCI card: | without optional PCI card |
| Ports: | 1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), 1x VGA, 2x 1GbE RJ45, 3x USB 3.0 Type A |
| Power supply: | 2x 800W |
| RAID controller: | Fujitsu Praid EP400i |
| RAM generation: | DDR4 |
| Scope of delivery: | Server as described, without software, hdd blinds or caddies, 2x Power cable, Without rail kit |
| Slots for hard disks: | 2.5 Inch, 8x |
| Type: | 19 Inch Rack Server |
| CPU model: | Intel Xeon Gold 5122 |
Fujitsu
Name: Fujitsu Technology Solutions GmbH
Anschrift: Mies-van-der-Rohe-Straße 8, 80807 München, Deutschland
Telefon: +49 (89) 62060-0
E-Mail-Adresse: cic@fujitsu.com
Security adviceElectrostatic discharge (ESD):
Wear ESD wristbands when working with internal components and ensure that the devices are properly earthed to prevent damage from static electricity.
Temperature protection and ventilation:
Keep flammable materials away from the server. Install suitable smoke detectors and fire-fighting systems near the server room. Ensure sufficient airflow. Do not block any ventilation slots to avoid overheating. Avoid placing the server in closed cabinets without ventilation. Keep the ambient temperature within the limits specified by the manufacturer.
Cable management:
Lay cables neatly to avoid tripping hazards and damage. Use cable management arms or clips to improve organisation.
Electrical safety:
Only use earthed sockets and tested mains cables and avoid overloading the circuits. Ensure that the mains cable is free from damage. Reduce the risk of short circuits by disconnecting the power sources before carrying out maintenance work. For models with a redundant power supply, disconnect all power cables before carrying out maintenance work to minimise electrical hazards.
Cleaning and maintenance:
For devices with multiple power supply units, all power sources must be disconnected before working on the device in order to completely deactivate the power supply. Never work on a server that is switched on. Ensure that all components have cooled down completely before touching or replacing them. Clean the ventilation openings and regularly check the hardware for dust and loose connections to ensure optimum performance and service life.
Assembly and disassembly:
Place the server in a stable, well-ventilated rack or on a suitable flat surface that can support the weight. Avoid locations with vibrations or inclinations to prevent tipping. Ensure that the mounting surface can support the weight of the server. Heavy components should be mounted at the bottom of the rack to ensure balance. Install only one device at a time to avoid instability.
Access protection:
The server should be installed in a secure area that is only accessible to authorised persons. Use racks with locks, shields or other physical security measures.
Battery safety:
If the server uses an internal battery (e.g. CMOS battery), only replace it with a compatible type. Dispose of old batteries in accordance with local regulations.
Transport and storage:
Transport the servers safely and use suitable packaging. Remove all external cables and secure moving parts before transport. Avoid violent movements that could lead to internal damage.
